Front 5000 Series XD Brake Ring
Front 5000 Series XD Brake Ring

Front 5000 Series XD Brake Ring

Sku
    DBA52372.1EXD
Diameter (mm):
    396
Axle:
    Front
Per Car Qty Required
    2

5000 SERIES XD features non directional cross drilled and dimpled design. The XD finish provides cooling benefits above the HD finish along with enhanced sports aesthetics.

XD utilises a mix of dimples and drilled holes to provide enhanced structural support above transitional cross drilled techniques.

We don’t recommend XD rotors for track use.

Where To Buy

Technical Specs

Axle
    Front
Vane Design
    KP Vents
Outer diameter[mm]
    396
Height [mm]
    34
Brake Disc Thickness [mm]
    34
Minimum Thickness [mm]
    32
Centering Diameter [mm]
    208
Number of Holes
    10
Number of Holes
    10
Pitch Circle Diameter [mm]
    228
Surface Design
    Cross Drilled/ Dimpled

Package Specs
