Front Street Series XGold Brake Rotor
Front Street Series XGold Brake Rotor

Front Street Series XGold Brake Rotor

Sku
    DBA2456X
Diameter (mm):
    300
Axle:
    Front
Per Car Qty Required
    2

Street Series X Gold provides all the benefits of Street Series, with a premium non-directional cross drilled and slotted design, plus an attractive gold finish on the rotor hub.

The introduction of our unique cross drilled and slotted design increases the number of exit points, allowing more brake pad friction dust and gases to escape through both the cross drilled holes and slots, resulting in better braking performance.

While providing a similar performance benefit to the T2 slot, the X Gold is a popular alternative for show cars.

X Gold is denoted by the suffix (X) in Street Series part numbers.

Where To Buy

Technical Specs

Axle
    Front
Vane Design
    KP Vents
Outer diameter[mm]
    300
Height [mm]
    47.3
Brake Disc Thickness [mm]
    28
Minimum Thickness [mm]
    26
Centering Diameter [mm]
    69
Number of Holes
    5
Number of Holes
    5
Pitch Circle Diameter [mm]
    114.3
Surface Design
    Cross Drilled/ Slotted

Package Specs

Technical Specs:

AxleFront
Vane DesignR KP Vents
Outer diameter[mm]300
Height [mm]47.3
Brake Disc Thickness [mm]28
Minimum Thickness [mm]26
Centering Diameter [mm]69
Number of Holes5
Weight [kg]8.74
Pitch Circle Diameter [mm]114.3
Surface DesignCross Drilled/ Slotted
