Rear Street Series HC Brake Rotor
Rear Street Series HC Brake Rotor
Rear Street Series HC Brake Rotor
Rear Street Series HC Brake Rotor

Rear Street Series HC Brake Rotor

Sku
    DBA3151HOE
Diameter (mm):
    300
Axle:
    Rear
Per Car Qty Required
    2

Adopting the two-piece OEM design, DBA offers its own version of a Hybrid Composite (HC) rotor, composed of a cast iron braking surface (disc ring) and an aluminium or steel hat, which are permanently bonded together by a series of rivets or through co-casting. The rotor features DBA’s own iron composition for enhancement. Its two-piece design may reduce the overall weight by up to 15% compared with a conventional one-piece rotor. Full R90 certification provides additional peace of mind.

The Street Series Hybrid Rotor range offers an attractive replacement alternative to owners of mainly high-end European vehicles.

Hybrid rotors are denoted by the suffix (HOE) in Street Series part numbers.

Where To Buy

Technical Specs

Axle
    Rear
Outer diameter[mm]
    300
Height [mm]
    46
Brake Disc Thickness [mm]
    12
Minimum Thickness [mm]
    10.3
Centering Diameter [mm]
    69
Number of Holes
    5
Number of Holes
    5
Pitch Circle Diameter [mm]
    112
Surface Design
    Cross Drilled/ Dimpled

Package Specs

Technical Specs:

AxleRear
Outer diameter[mm]300
Height [mm]46
Brake Disc Thickness [mm]12
Minimum Thickness [mm]10.3
Centering Diameter [mm]69
Number of Holes5
Weight [kg]5.6
Pitch Circle Diameter [mm]112
Surface DesignCross Drilled/ Dimpled
