Rear Street Series HC Brake Rotor
Rear Street Series HC Brake Rotor

Rear Street Series HC Brake Rotor

Sku
    DBA3357HOE
Diameter (mm):
    300
Axle:
    Rear
Per Car Qty Required
    2

Adopting the two-piece OEM design, DBA offers its own version of a Hybrid Composite (HC) rotor, composed of a cast iron braking surface (disc ring) and an aluminium or steel hat, which are permanently bonded together by a series of rivets or through co-casting. The rotor features DBA’s own iron composition for enhancement. Its two-piece design may reduce the overall weight by up to 15% compared with a conventional one-piece rotor. Full R90 certification provides additional peace of mind.

The Street Series Hybrid Rotor range offers an attractive replacement alternative to owners of mainly high-end European vehicles.

Hybrid rotors are denoted by the suffix (HOE) in Street Series part numbers.

Where To Buy

Technical Specs

Axle
    Rear
Outer diameter[mm]
    300
Height [mm]
    48.5
Brake Disc Thickness [mm]
    22
Minimum Thickness [mm]
    19.4
Centering Diameter [mm]
    69
Number of Holes
    5
Number of Holes
    5
Pitch Circle Diameter [mm]
    112
Surface Design
    Cross Drilled/ Dimpled

Package Specs

Technical Specs:

AxleRear
Outer diameter[mm]300
Height [mm]48.5
Brake Disc Thickness [mm]22
Minimum Thickness [mm]19.4
Centering Diameter [mm]69
Number of Holes5
Weight [kg]7.13
Pitch Circle Diameter [mm]112
Surface DesignCross Drilled/ Dimpled
