Rear Street Series T2 Brake Rotor
Rear Street Series T2 Brake Rotor

Rear Street Series T2 Brake Rotor

Sku
    DBA563S
Diameter (mm):
    269
Axle:
    Rear
Per Car Qty Required
    2

Street Series T2 rotor provides all the benefits of DBA’s Street Series direct replacement rotors with the added benefit of the introduction of DBA’s patented T2 slot design.

The T2 design features precise CNC machined bi symmetrical slots, resulting in a quieter, more responsive brake pedal feel.

The T2 increases the number of exit points, allowing friction dust and gases to escape thus enhancing the pad bite.

T2 is denoted by the suffix (S) in Street Series part numbers.

Where To Buy

Technical Specs

Axle
    Rear
Vane Design
    Solid
Outer diameter[mm]
    269
Height [mm]
    56
Brake Disc Thickness [mm]
    9
Minimum Thickness [mm]
    7.5
Centering Diameter [mm]
    55
Number of Holes
    5
Number of Holes
    5
Pitch Circle Diameter [mm]
    100
Surface Design
    Slotted

Package Specs

Technical Specs:

AxleRear
Vane DesignR Solid
Outer diameter[mm]269
Height [mm]56
Brake Disc Thickness [mm]9
Minimum Thickness [mm]7.5
Centering Diameter [mm]55
Number of Holes5
Weight [kg]3.94
Pitch Circle Diameter [mm]100
Surface DesignSlotted
